VAPOUR ABSORPTION TYPE REFRIGERATION SYSTEM TRAINER

Make: EEI, Model: RAC-VAR040, Origin: India

TECHNICAL SPECIFICATIONS:

• The System has no moving parts at all, which makes it Silent and very durable.

• Refrigerant: Mixture of three fluid system Ammonia (NH3) + Water (H2O) +

Hydrogen (H2)

• Gases: Non – CEC, Non – HCFC, Non – FCKW, Non – Freon

• Mode of heating System: Externally heated by electric resistance heater

• Evaporator: Coil Type evaporator with facility to determine performance efficiency

ratio with the help of supply water facility.

• Volume of Cabinet: 40 Ltrs.

• Voltage Input – 65 Watts, Electrical Consumption/24 Hrs. – 0.8 kWh, Auto Defrost.

• Experimental Capability Actual, theoretical COP

• Manual Self-explanatory Instruction manual, sample calculation

• Digital volts meter, ammeter and energy meter for power input measurements

Thermocouples Teflon coated (PT-100 type)-6 nos.

• The whole system is mounted on a Metallic powder coated frame and panel with

Caster Wheels

• Floor area required: 0.8mtr x0.8 mtr floor space

• Power supply required: single phase, 230volts, 5 amps, and 50Hz.
