COMPUTERIZED AIR CONDITIONING SYSTEM TRAINER (SPLIT TYPE)

This Air Conditioning Study Unit is a laboratory scale working model with all instrumentations mounted on a portable trolley made of MS Tube Frame with powder coated panel with Caster Wheels.

SYSTEM SPECIFICATIONS:

• Indoor unit includes copper finned coil of 1.5TR with Provision for variable airflow rate and remote-control system mounted on the panel make LG/VOLTAS/ equivalent- 1no

• Outdoor unit includes air-cooled condenser of suitable Capacity with Fan, Compressor Hermetically Sealed, Rotary type 1.5 TR GMCC/ equivalent. -1no

• Expansion System Capillary/auto expansion system. -1no

• Refrigerant Freon R32- 750gm approx.

• Liquid filled back connection Gauges for HP and LP- 2nos

• HP-LP cut-out (analogue)-1no

• Flow Visualization 1/4th size Site Glass-1no

Measuring instruments with pc interfaced facility:

• Dual power watt meter single phase 230 volts – 1pc

• Six-channel temperature scanner, -50 to 150°C – 1no

• Thermocouples Teflon coated (PT-100 type)-6 nos.

• 24volts dc Pressure transducer -2nos

• Digital dual pressure indicator. -1no

• Digital refrigerant flow sensor. -1no

• Digital Dual channel RH indicator -1no

• RH sensor in and out -2nos

• Digital Anemometer for Air Flow Measurement-1no

Experimental Capability

• Actual, theoretical COP, Psychometric Processes

• Manual Self-explanatory Instruction manual

Data acquisition with application software

National instruments Lab View based application software with data acquisition signal conditioner to log the data and saved the files in excel and word format.

Service required

• Power supply requirements 230volts, single phase 15amps, 50Hz.

• Floor space requirement: 1200x600x1400mm.
